Columbia AC Electric Hoists

AC Electric Hoists


Our Columbia AC Electric Hoists feature compact and efficient transplant reductions that require less input power, increase production while minimizing hoist size and weight. TEFC, UL-listed brake motors stay cooler during long duty cycles and their load holding brakes apply automatically.

Sealed construction keeps gears, shaft surfaces and bearings lubricated - no pillow blocks that require greasing. Modular design allows drum size changes and a wide range of gear ratios and motor sizes provide the performance required for your application. A full selection of options from single-speed drum switches to synchronized muli-unit/multi-axis systems put you in full control of your AC Electric Hoists.

To discuss project specifics or request a quote contact us at (503) 626-0654.


Planetary Reductions

Brake Motors

Sealed Construction

Modular Design

Custom Units Available

Wide Range of Options

Available Products

Application Considerations

Determining the required line pull is the most important factor in selecting the proper winch or hoist for your application.

More Information on Determining Line Pull >>

Line speed is the distance the load travels over a given amount of time.

More Information on Determining Line Speed >>

Horsepower is a measurement of the rate (line speed) at which work (line pull) is performed.

See More Information on Horsepower >>

Travel distance is the distance the load must move. Determining travel distance is more difficult in positioning systems, when using multiple pieces of line or when line stays in the system.

More Information on Travel Distance >>

Wire rope size is determined primarily by the weight of the load being pulled or lifted.

More Information on Wire Rope Sizes and Break Strengths >>

The duty cycle of a winch or hoist is a measurement of how often it is used in a given amount of time.

More Information on Determining Duty Cycle >>

To prevent excessive wire rope wear and damage and ensure the safety of operators, a location that permits proper fleet angle is necessary to let the wire rope spool uniformly onto the drum.

More Information on Fleet Angle Considerations >>

The temperature, humidity, exposure to elements, ventilation, and elevation can all play in a role when specifying the proper winch or hoist for the job.

More Information on Operating Environment >>

Do you need to pull something instead of lifting it? Explore our winches here >>>

Do you need a pneumatic system? Explore our line of pneumatic hoists here >>>

AC Electric Hoists In Use

Columbia Construction Hoist Systems Have Critical Role On George Washington Bridge Project

Application: George Washington Bridge Suspension Cable Replacement
Skanska-Koch Joint Venture
Location:  New York City
Hoist Model:  Columbia HU19500–4A17-L-01 AC Electric Hoists (Five units)
Line Pull:  19,500 pounds on the first layer
Line Speed:  28 feet per minute on the first layer
Wire Rope Capacity:  1,497 feet x 5/8” 6X36 EIPS wire rope
Power Source:  460 VAC / Three Phase / 60 Hz
Special Features (Hoist):

20.0 HP TEFC UL-listed brakemotor
Mounting code: FM-12
Rated for continuous duty
Automatic, load-suspending braking system
Tension roller with linear potentiometer
Gray epoxy (Devran 261QC) overcoat
1200 feet x 5/8” EIPS wire rope on each hoist

Special Features (Controls):

Hoists are paired on custom fabricated skids with an…

Columbia Rooftop Crane and Hoist

Application:  Construction project davit with AC electric hoist
P & M Mechanical, Inc.
Location:  Birmingham, AL
Davit Model:  Columbia 5AFM Davit crane with pedestal base mount
Hoist Model:  Columbia HD670-1A34-L-11 AC electric hoist
Line Pull:  500 pounds on the first layer
Line Speed:  29 feet per minute on the first layer
Wire Rope Capacity:  99 feet x 3/16” diameter wire rope with latching hook
Power Source:  115 VAC / Single phase / 60 Hz…

Columbia Jet Ski & Kayak Hoist

Application:  Lifting jet skis, kayaks and other personal watercraft
Customer:  Dalgleish Construction Company
Location:  Austin, TX
Hoist Model:  Columbia HD1300-1A34-L-11 AC Electric Hoist
Line Pull:  1,300 pounds on the first layer
Line Speed:  15.0 feet per minute on the first layer
Power Source:  115 VAC / Single phase / 60 Hz…
