Columbia Parachute Hoists Specified for US Navy Drying Tower

Application: Columbia parachute hoists lift multiple parachutes to dry after cleaning
Customer:  Noble Supply / US Navy
Location:  Pearl Harbor, Hawaii
Hoist model:  Columbia HD670-1A34-L-11
Line pull: 670 pounds
Line speed: 30 feet per minute
Power source: 115 VAC / Single Phase / 60 Hz
Special features:  Hoists: Epoxy overcoat, stainless steel fasteners, stainless steel wire rope and cable tension plate.  Custom control panel: Eight (8) position hoist selector switch, UP/DOWN momentary contact push buttons and power indicator lights.  Sheaves: Eight (8) VLS-3 vertical lead sheaves with low profile mounting, epoxy overcoat and stainless steel fasteners….

Columbia Portable Hoist Assists With Maintenance and Installations

Application:  General purpose contractor’s portable hoist package
Customer: Wisconsin Power and Light Co.
Location: Sheboygan, WI
Hoist Model: Columbia HD2000-1A34-F-02
Line Pull: 2,000 pounds on the first layer
Line Speed: 11.8 feet per minute on the first layer
Wire Rope Capacity: 217 feet x ¼” diameter wire rope
Power Source: 115 VAC / Single phase / 60 Hz
Special Features:  -02 drum, Wire rope pressure plate, Aluminum base plate, Carry handle…

Columbia Film Roll Hoist Simplifies Lamination Process

Application:  Columbia Film Roll Hoist lifts 400-pound rolls of laminating film onto a production table.
Customer:  Autofeeds Inc.
Location:  Green Bay, WI
Hoist Model: Columbia HD1300-1A34-F-11
Line Pull:  1,300 pounds on the first layer
Line Speed:  15 feet per minute on the first layer
Wire Rope Capacity: 40 feet x 3/16” diameter wire rope with latching hook
Power Source:  115 VAC / Single Phase / 60 Hz
Special Features:  Equipped with full voltage controls – NEMA 12 rated hand held pendant with six-foot lead.  Controls are integrated with a proprietary overload/over travel system supplied by Autofeed….

Columbia Dual Beam Trolley Hoist System

Application:  Columbia trolley hoist system for an OEM’s dual beam trolley
Customer
:  Vo-Tech, Inc
Location:  Crystal Lake, IL
Hoist model:  Columbia HD1300-2A34-X-11
Line Pull:  1,300 pounds on the first layer
Line Speed:  4 feet per minute on the first layer
Power Source:  230 VAC / Three Phase / 60 Hz
Special features:  Inverter-duty brakemotor and quick-mount brackets…

Columbia Strap Hoist Provides Maintenance Solution

Application: Strap hoist for a jib crane with restricted headroom
Customer: General Cable Technologies Corporation
Location: Paragould, AR
Hoist model: Columbia HD1300-1A34-F-15
Special features: Strap option and upper limit switch
Line pull: 1,300 pounds on the first layer
Line speed: 15 feet per minute on the first layer
Power source: 115 VAC / Single Phase / 60 Hz

Columbia Aircraft Assembly Hoist Positions Components

Application: Two strap hoists for positioning nose cone during aircraft assembly.
Customer Location: Marrietta, GA
Line Pull: 650 pounds per AC electric hoist
Line Speed: 21 feet per minute
Strap Capacity: 27 feet x 2” wide strap
Power Source: 115 VAC / Single Phase / 60 Hz
Special Features: Strap drum conversion, custom rotation fixture
