Custom Columbia Dam Hoist System

Application:  Lifting fish screens weighing 24,000 pounds and 7,000 pounds
Customer:  Tacoma Power and Light
Location:  Cowlitz Falls Dam, Washington State
Hoist Model:  Columbia HL14000-4A17-L Dual Drum Hoist

Line Pull:  14,000 pounds on the first layer (single line)
Line Speed:  0-12 feet per minute on the first layer (single line)
Wire Rope Capacity:  29′ x 5/8″ wire rope per drum
Power Source:  460 VAC / Three phase / 60 Hz…

Columbia Turbine Hoist Assists Maintenance Procedure

Application:  Columbia turbine hoist used to raise and lower submerged turbine for maintenance and adjustments
Customer:  Marine Renewable Energy Collaborative – New England
Location:  Marion, MA
Hoist Model:  Columbia HL12000-2A17-L-02 AC Electric Hoist
Line Pull:  12,000 pounds on the first layer
Line Speed:  5 feet per minute on the first layer
Wire Rope Capacity:  55 feet x 1/2″ stainless steel wire rope with thimble eye
Power Source:  230 VAC / Single Phase / 60 Hz…

Columbia ROV Testing Hoist

Application:  Deep Sea ROV Testing Hoist
Customer:
Woods Hole Oceanographic Institution
Location:  Woods Hole, MA
Hoist Model:  Columbia HD1000-1A17-F-11
Line Pull:
1,000 pounds on the first layer
Line Speed:  7.7 feet per minute on the first layer (customer requested speed)
Power Source:  115 VAC / Single phase / 60 Hz
Special Features:  Reduced speed required for testing application…

Columbia Strap Hoists Help Hatchery Sort Salmon

Application:  Columbia Strap Hoists Help Hatchery Sort Salmon
Customer:  Bonneville Fish Hatchery
Location:  Cascade Locks, OR
Hoist Model:  Columbia HD900-4A34-X-15
Line Pull:  900 pounds on the first layer
Line Speed:  21 feet per minute on the first layer
Power Source:  460 VAC / Three Phase / 60 Hz
Special Features:
  2.0” wide strap; drum modification with tie rod strap guide
  Custom three phase brake motor (3/4 HP totally enclosed, Fan Cooled and UL listed)…

Columbia Barge Positioning Winch System Assists Grain Loading Operation

Application:  Barge Positioning Winch System for Grain Loading
Customer:  Mid-Columbia Producers
Location:  Moro, Oregon
Hoist Model:  Columbia WL9000-4A17-X-02
Line pull:  9,000 pounds on the first layer
Line speed:  16 feet per minute on the first layer
Wire rope capacity:  368 feet x 5/8″ wire rope
Power source:  460 VAC / 3 Phase / 60 Hertz
Special features:  In-line gearbox with 5.4 HP single phase brake motor that is IP66 rated with a strip heater….

Columbia Flow Control Hoist Assists Fish Ladders

Application:  Fish Ladder Flow Control Hoist
Customer:  Portland General Electric
Location:  Willamette Falls, Oregon City, Oregon
Hoist Model:  Columbia H21500-4A17-L-00
Line Pull:  21,500 lbs. single layer and 43,000 lbs with 2-part line
Line speed:  4.5 feet per minute with 2-part line
Brake rating:  140,000 lbs
Power source:  460 VAC / Three phase / 60 Hz
Special features:  Dual 1½ HP brakemotors, 12” drum core grooved for dual 5/8” wire rope assemblies, 70.5” drum width, 4-cam rotary limit switch and custom base plate. Dual multi-turn potentiometers for position locating. Custom NEMA 4X control panel with variable frequency drive. Installed on the panel face: UP/DOWN momentary buttons, LOCAL/REMOTE switch for future remote control, LED…

Columbia Mast Hoists Provide Low Overhead Solution for Tugs

Application:  Mast hoists lower radar and electronics for low headroom clearance
Customer:  Foss Maritime
Location:  Seattle, Washington
Hoist model:  Columbia HF1500-2A34-X-02
Line pull:  1,500 pound on the first layer
Line speed:  24 feet per minute on the first layer
Power source:  230 VAC / 3 Phase / 60 Hz
Special features:  Customer provided controls…

Columbia Dinghy Hoists Sail With The Oliver Hazard Perry

Application: Launching and retrieving sailing vessel dinghies
Customer:  Oliver Hazard Perry
Location:  Newport, Rhode Island
Hoist Model: Columbia HG3300-2A33-L-00 AC electric hoists
Line pull: 1,625 pounds on first layer (for each hoist)
Line speed: 14.9 feet per minute
Power source: 208 VAC / Three phase / 60 Hz
Special Features: Washdown-duty motor, custom drum assembly, epoxy overcoat, manual operation adaptor, stainless steel fasteners and stainless steel wire rope assemblies…

Columbia Two Line Dam Hoist Raises Oil/Water Separator

Application:  Two line dam hoist for lifting and lowering oil/water separator on Columbia River
Customer:  Unique Metalcraft Inc.
Line Pull: 4,000 pounds on the first layer
Line Speed: 12 feet per minute on the first layer
Wire Rope Capacity: Two (2) sections, each holding 35’ x 3/8” wire rope
Power Source:  460 VAC / Three phase / 60 Hz
Special Features: Right angle gearbox for compact installation, custom rotary limit switches, stainless steel grooved drum and fasteners…

Columbia Port Crane Winch Positions I-Beam Rails

Application:  Pulling small I-beam rails into place for installation on fixed port cranes.
Customer:
Cargotec Crane & Electric
Location:  Elizabeth, NJ
Winch Model:  Columbia WD1000-1A34-F-01
Line Pull:  1,000 pounds on first layer
Line Speed:  22.5 feet per minute on the first layer
Wire Rope Capacity:  213’ of 3/16” wire rope
Power Source:  115 VAC / Single Phase / 60 Hz
Special Features:  Tension plate, base plate, carry handle…
